OPTION 11 FAST PULSE AND HIGH POWER
Annex-B-18
Table B-6 ALC linearity at 2050 MHz
RF level (dBm) RF level min.
(dBm)
Result (dBm) RF level max.
(dBm)
−4 −5.2
_______
−2.8
−3 −4.2
_______
−1.8
−2 −3.2
_______
−0.8
−1 −2.2
_______ +0.2
0
−1.2
_______ +1.2
1
−0.2
_______ +2.2
2 +0.8 _______ +3.2
3 +1.8 _______ +4.2
4 +2.8 _______ +5.2
5 +3.8 _______ +6.2
6 +4.8 _______ +7.2
7 +5 _______ +9
8 +6 _______ +10
9 +7 _______ +11
10 +8 _______ +12
11 +9 _______ +13
12 +10 _______ +14
12.1 +10.1 _______ +14.1
12.2 +10.2 _______ +14.2
12.3 +10.3 _______ +14.3
12.4 +10.4 _______ +14.4
12.5 +10.5 _______ +14.5
12.6 +10.6 _______ +14.6
12.7 +10.7 _______ +14.7
12.8 +10.8 _______ +14.8
12.9 +10.9 _______ +14.9
13 +11 _______ +15
14 +12 _______ +16
15 +13 _______ +17
16 +14 _______ +18
17 +15 _______ +19
18 +16 _______ +20
19 +17 _______ +21
