Aeroflex 2023A - Page 273

OPTION 11 FAST PULSE AND HIGH POWER
Annex-B-26
Table B-14 Pulse mod. RF output at +16 dBm
Carrier frequency
(MHz)
RF level min.
(dBm)
Result (dBm) RF level max.
(dBm)
0.1 +15 _______ +17
1 +15 _______ +17
3 +15 _______ +17
9 +15 _______ +17
30 +15 _______ +17
90 +15 _______ +17
210 +15 _______ +17
330 +15 _______ +17
450 +15 _______ +17
570 +15 _______ +17
690 +15 _______ +17
810 +15 _______ +17
930 +15 _______ +17
1050 +15 _______ +17
1170 +15 _______ +17
1200 +15 _______ +17
2023B and 2025
1201 +14 _______ +18
1290 +14 _______ +18
1410 +14 _______ +18
1530 +14 _______ +18
1650 +14 _______ +18
1770 +14 _______ +18
1890 +14 _______ +18
2050 +14 _______ +18
2025 ONLY
2250 +14 _______ +18
2370 +14 _______ +18
2400 +14 _______ +18
2025 ONLY (+11 dBm)
2510 +9 _______ +13
