Introduction Ensemble Epaq Hardware Manual
Feature Details
Command Execution
Modes
AUTO Program runs to completion upon startup
SINGLE Full debug capability to step, step over, step into individual
program lines
IMMEDIATE Commands are executed upon entry
JOG Axes controlled with jog pad on front panel or optional
joystick
REMOTE Command execution controlled by remote host through
Ethernet, RS-232, or IEEE-488 communications port via
ASCII strings
Input/Output Standard The chassis includes: ESTOP, RS-232, GPIB Each
amplifier axis includes: CW, CCW, and Home limits; DIR,
CLK, Hall effects, amplifier thermistor; 1 channel of 16-bit
A/D per axis (±10 VDC)
Optional IO Board
(can be added to
each amplifier axis)
Eight opto-inputs with the IO board option; eight opto
outputs with the IO board option; sinking and sourcing
selection is available through the parameters; 5-24 VDC
can be used with any IO pins; single axis PSO (each axis
with optional IO; one additional 12-bit (±10 VDC) input and
one additional 16-bit (±5 VDC) output; brake relay: 0.5
amp solid-state relay available with option board;
secondary TTL RS-422 auxiliary encoder input; position
latch with 50 ns position capture latency
Encoder Inputs TTL RS-422 standard, and on optional IO auxiliary encoder input; optional
amplified sine encoder input on primary encoder channel; programmable
resolution up to 1024 times the analog encoder resolution; 10 MHz TTL RS-422
square wave primary or auxiliary encoder; 250 kHz amplified sine primary (with
optional onboard encoder multiplier board)
Additional Interfaces Serial 10/100 Base T Ethernet communication interface for
system setup, application networking, Epaq-to-Epaq
communications, embedded programming, immediate
commands, and Modbus over TCP; USB communication
interface for system setup, application networking,
Windows® PC control interface; RS-232 port with
programmable baud rate, length, parity, stop bits (second
RS-232 port optional)
Machine Control ESTOP discrete input to stop all axes
Display Backlit 8 x 40 character LCD
Keypad 5-key input pad
Other IO Parallel One optional GPIB (IEEE-488)
Power Output
Capability
600 watt, 54 VDC power supply for bus power to axis drives; optional 24 VDC
www.aerotech.com Chapter 1 3
To Next Page
