Ensemble Epaq Hardware Manual Maintenance
5.2. Power Board
Figure 5-2 highlights the important components located on the power board assembly.
D A N G E R : Always disconnect the Mains power connection before opening the Ensemble
Epaq chassis.
Drawing Number:
690C1645
TB1
TB5
TB6
TB7
TB8
TB2
TB3 TB4
F3
3 ASB
3 AG
F4
4 ASB
3 AG
F1
3 ASB
3 AG
F2
4 ASB
3 AG
Figure 5-2: Power Board Assembly
