Maintenance Ensemble Epaq Hardware Manual
Table 5-3: Control Board Jumper Configuration
Jumper Setting Description
JP1 1-2
(1)
Normal
2-3 Watchdog defeated
(1) Default
Table 5-4: Serial Communication Mode Jumper Select
Jumper Setting
Mode JP2 JP3 JP4 JP5 JP6 JP7 JP8 JP9
RS-232
(1)
1-2 1-2 1-2 1-2 1-2 1-2 1-2 1-2
RS-232
(2)
1-2 1-2 1-2 1-2 2-3 2-3 1-2 1-2
RS-422 2-3 2-3 2-3 2-3 1-2 1-2 1-2 2-3
RS-485 2-3 1-2 2-3 2-3 1-2 1-2 2-3 2-3
(1) Default
(2)Reversed
