Aerotech Ensemble Epaq User Manual

Maintenance Ensemble Epaq Hardware Manual
5.4. Integrated Axis I/O Expansion Board (Amplifier)
The figure below highlights the important components located on the -IOoption board. Refer to Chapter 3: -
IO Expansion Board for a description of user accessible features.
D A N G E R : Always disconnect the Mains power connection before opening the Ensemble
Epaq chassis.
Drawing Number: 690D1616
F2
BRAKE
POWER
AUX ENC
AIN/AOUT OPTO-IN OPTO-OUT
F1
F3 F4 F5 F6
MICROSMD005F-2
F7 F8 F9
F10
Figure 5-5: -IO Option Board Assembly
www.aerotech.com Chapter 5 85
