Ensemble Epaq Hardware Manual Maintenance
5.5. Fuse Replacement
Table 5-5 lists the manufacturer and Aerotech’s part number for typical replacement fuses. Additional fuse
information may be provided on a system drawing supplied with the unit.
Table 5-5: Fuse Information
Description Fuse Rating Aerotech P/N Manufacturer P/N
ACInlet (rear panel) ACpower
fuses
AC1 F1/F2 10 A S.B. EIF00120 LittelFuse 215010.P
Bus Power Supply Fuses
(Figure 5-2)
Refer to your system drawing.
F1, F3
2 AS.B. EIF00102 LittelFuse 313002P
3 AS.B. EIF00103 LittelFuse 313003P
F2, F4 4 A S.B. EIF00104 LittelFuse 313004P
MPAmplifier fuses (Figure 5-3)
F1 is the Control Power fuse
and F2 is the Bus Power fuse
F1
(1)
2 A S.B. EIF00136 LittelFuse 255002
F2
5 A S.B.
(5 mm)
EIF00179 Wickman 1951500
MLAmplifier Bus fuses (Figure
5-4)
F1, F2 5 A S.B. EIF01025 LittelFuse 3721500411
1. F1 is soldered to the circuit board, contact Aerotech for repair if fuse is open.
D A N G E R : Residual voltages greater than 60V may be present inside the Ensemble Epaq
chassis for longer than 5 seconds after power has been disconnected.
D A N G E R : Always disconnect the Mains power connection before opening the Ensemble
Epaq chassis.
86 Chapter 5 www.aerotech.com
