© Agilent Technologies 1989–2002 Agilent 3070 / 79000 Site Preparation 9-11
Chapter 9: Site Preparation – Receiving and Moving Instructions: Uncrating The System
Figure 9-5 Attaching the ramp
8 Remove all four shipping brackets from the testhead
and pallet.
9 Roll the testhead down the ramp and onto the floor.
NOTE
Advise the customer to save the pallet, ramp, and
shipping materials in case the customer needs to
ship the system to another facility. The only safe
way to ship the testhead is using the pallet and
shipping materials provided.
UNCRAT3.WPG
Testhead
Bolt
Ramp
Platform
Foot
