Chapter 10: Site Preparation – Power Requirements for Older Systems: Series 3 Power Requirements and Connections (Prior to May 2000)
Single-Phase Center-Tap
Neutral
AWY 100 / 200 Table 10-17 on page 10-100 Figure 10-66 on page 10-106
0E3 110 / 220 Table 10-17 on page 10-100 Figure 10-66 on page 10-106
0EG 115 / 230 Table 10-17 on page 10-100 Figure 10-66 on page 10-106
0EH 120 / 240 Table 10-17 on page 10-100 Figure 10-66 on page 10-106
Table 10-11 Series 3 and 79000 cross-reference tables (single-phase) (continued)
Description
E1135C
Power Option Voltage
Wire and Breaker Size Table
Number Wiring Diagram
L1
L2
G
N
