Chapter 10: Site Preparation – Power Requirements for Older Systems: Tester Power Requirements (Series I/II)
Table 10-24 E1099A option 0E3 mains requirements
Device Current (Amps) 100/200 Volts Single-Phase w/Center Tap
Left & Right Outlets
J50-J53, J64-J71
Module 1 11.4 10.5
Module 2 11.4 10.5
Module 3 11.4
Module 4 11.4
+5 V STC P.S. #1 3.4 3.1
+5 V STC P.S. #2 3.4 3.1
+5 V STC P.S. #3 3.4
+5 V STC P.S. #4 3.4
Front Panel Outlets
J40,J41 - J44-J46 J42,J43 - J47-J49
DUT Power #1 6.0 6.0
DUT Power #2 6.0 6.0
DUT Power #3 6.0
DUT Power #4 6.0
Aux. Equipment 4.0 3.0 1.0
Controller/Peripherals 40.0
* Total current: Phase A - B Phase B - N Phase A - N
