© Agilent Technologies 1989–2002 Agilent 3070 / 79000 Site Preparation 10-141
Chapter 10: Site Preparation – Power Requirements for Older Systems: Tester Power Requirements (Series I/II)
Table 10-39 Single- phase with center tap neutral (AWY, 0E3, 0EG, 0EH)
System Type
POTS Bay 327X 317X 307X
Testhead Support Bay
Breaker Size in Amps
20 30 50 50 30
SO Cord Conductor Size mm2 (American Wire Gauge - AWG)
4 (12) 6 (10) 10 (8) 10 (8) 6 (10)
Table 10-40 Single-phase earthed (05M, 05F, 05J)
System Type
POTS Bay 327X 317X 307X
Testhead Support Bay
Breaker Size in Amps
20 25 50 50 30
SO Cord Conductor Size mm2 (American Wire Gauge - AWG)
4 (12) 6 (10) 10 (8) 10 (8) 6 (10)
