Chapter 10: Site Preparation – Power Requirements for Older Systems: Tester Power Requirements (Series I/II)
Table 10-37 2-phase open delta with center tap of one phase (05A)
System Type
327X 317X 307X
Breaker Size in Amps
20 30 50
SO Cord Conductor Size mm2 (American Wire Gauge - AWG)
4 (12) 6 (10) 10 (8)
Table 10-38 Single-phase wye w/neutral (05B, 05G, 05K)
System Type
327X 317X 307X
Breaker Size in Amps
30 40 70
SO Cord Conductor Size mm2 (American Wire Gauge - AWG)
4 (12) 6 (10) 6 (10)
