4-4 Agilent 4155C/4156C User’s Guide Vol.1, Edition 11
File Operations
Selecting a Mass Storage Device
Selecting a Mass Storage Device
To start a file operation, you must specify the mass storage device by selecting either
the built-in flexible disk drive or a network file system.
1. Press System key.
2. Select FILER softkey to display the SYSTEM: FILER screen.
3. Move the cursor to the DISK entry field.
4. Select one of the following secondary softkeys.
FLOPPY Specifies the diskette in the built-in flexible disk drive.
Insert a diskette into the built-in flexible disk drive.
drive name If you have set up a drive label in the NETWORK DRIVE
SETUP table, this label will appear as a softkey. Up to four
softkeys can be added this way.
Before selecting one of these directories, it must be exported so
that it can be mounted by the 4155C/4156C.
When this softkey is pressed, the 4155C/4156C mounts the
directory on an NFS server, and displays the file catalog in the
FILE CATALOG area. The directory name will be shown next
to the DISK entry field, and it will be the root directory.
To unmount the directory, choose another secondary softkey or
turn off the 4155C/4156C.
