Print/Plot Function
Supported Peripherals
Connecting Peripherals
The 4155C/4156C has both GPIB and parallel interfaces for connecting peripherals.
To connect the peripheral to the interface connector, use one of the following cables:
GPIB: Agilent 10833A/B/C/D GPIB cable or equivalent
parallel: HP C2950A/C2951A printer cable or equivalent
For more information on connecting peripherals, see “Connecting Instruments or
Peripherals” in Chapter 2.
If you use a remote printer via your printer server, connect the 4155C/4156C to your
LAN. For more information, see Chapter 3 and Setup Screen Reference manual.
HP LaserJet 6L
i
Parallel PCL, HR PCL,
HP-GL
B/W P/L 75, 100, 150,
180, 300,600
HP C1202A serial printer GPIB PCL B/W P 90, 150
HP ThinkJet (2225A/C/D) GPIB, Parallel PCL B/W P 75
HP PaintJet (3630A) GPIB PCL B/W, FIX, COLOR P
HP 7440A/7475A plotters GPIB HP-GL B/W, FIX L
HP 7550B plotter GPIB HP-GL B/W, FIX L
a. Available parameters for the COLOR/ B/W field on the PRINT/PLOT SETUP screen:
B/W = Black & White mode, FIX = Fixed color mode, COLOR = Color mode.
b. P = Portrait, L = Landscape
c. Available values for the output resolution setting.
d. For screen image dump only.
e. COLOR mode is available for HR PCL only. Available number of colors is 8.
f. 600 dpi for PCL only.
g. 600 dpi for B/W only.
h. Enter
\0033E into the TRAILER STRING field on the PRINT/PLOT SETUP screen before printing.
Else, the Form Feed indicator of the printer will blink after successful printing. To stop the blinking, press
the Form Feed button of the printer.
i. Additional memory is required when printing 2 graphs or 2 dumps on a sheet. Recommends total 2Mbyte
or more.
Model Interface Output Format
Color
a
P/L
b
Output
Resolution
(dpi)
c
To Next Page
