Agilent 4155C/4156C User’s Guide Vol.1, Edition 11 5-3
Print/Plot Function
Output Formats
Output Formats
The print/plot function supports PCL, HP-GL, and TIFF formats, and provides the
following five output modes:
PCL For making hard copies using a peripheral that supports PCL, or
for saving the hard copy image to a PCL file.
HR PCL High resolution PCL. For making hard copies using a peripheral
that supports PCL, or for saving the hard copy image to a PCL
file. Output quality is higher than the PCL mode.
HP-GL For making hard copies using a peripheral that supports HP-GL,
or for saving the hard copy image to an HP-GL file. Mainly
used for a plotter.
TIFF For saving screen images to a TIFF file.
HR TIFF High resolution TIFF. For saving screen images or
measurement graph hard copy images to a TIFF file. Output
quality is higher than the TIFF mode.
The display screens and output format available for each print, plot, or save function
are as follows:
1. All setup screens, except for GRAPH/LIST and KNOB SWEEP.
4155C/4156C Display Screens Output Format
Printing/plotting screen images (screen dumps) all PCL, HR PCL or HP-GL
Printing/plotting setup data lists
all setup
1
Printing/plotting measurement data lists GRAPH/LIST: LIST
Printing/plotting measurement data graphs GRAPH/LIST: GRAPHICS,
KNOB SWEEP
Saving screen images to a file all PCL, HR PCL, HP-GL,
TIFF or HR TIFF
Saving setup data lists to a file
all setup
1
PCL, HR PCL or HP-GL
Saving measurement data lists to a file GRAPH/LIST: LIST
Saving measurement data graphs to a file GRAPH/LIST: GRAPHICS,
KNOB SWEEP
PCL, HR PCL, HP-GL or
HR TIFF
