File Operations
Storing Results Data in Spreadsheet Format
Storing Results Data in Spreadsheet Format
1. Specify the mass storage device.
2. Display the results data on the GRAPH/LIST: LIST screen.
To display the GRAPH/LIST: LIST screen, press Graph/List key. If the
GRAPH/LIST: GRAPHICS screen is displayed, press Graph/List key again.
3. Select SPREAD SHEET softkey to display the ASCII SAVE setup fields.
For a list of files in the mass storage device, select FILE CATALOG softkey.
4. In the NAME field, enter the name of the file (with no file extension) in which
you want to save data. The file name may be:
• a maximum of 8 characters to store on a DOS diskette.
• To store data in a new file on the network file system, enter a file name, 36
characters maximum. The file name and directory path combined can be 58
characters maximum.
5. In the OUTPUT DATA field, enter the range of results data you want to save
(corresponds to NO. column on the LIST screen). The left field is the lower
limit and the right field is the upper limit.
Select ALL softkey to specify all results data.
6. In the UNIT field, select one for the following:
• ON softkey will save the unit of measure (such as V or ms) with the results
data. If the UNIT is ON, results data will be treated as string data.
• OFF softkey will not save the units of measure. Results data will be treated
as numeric data.
With UNIT ON or OFF, invalid data (----) will be treated as string data.
FUNCTION:ASCII SAVE
OUTPUT DATA (INDEX NO)
NAME
UNIT
DELIMITER
STRING MARK
<-->
