3-14 Agilent 4155C/4156C User’s Guide Vol.1, Edition 11
Connecting to Network
Using Network
Saving Spreadsheet Data
This example saves measurement result data to a file in the spreadsheet format.
Figure 3-8 shows an example setup to save spreadsheet data to the L-IDVG.TXT file
in the C:\D4156 directory of the NFS server.
1. Press the System key to display the SYSTEM: FILER screen.
2. Move the field pointer to the DISK field, and select a softkey to mount the
network file system.
3. Press the Graph/List key twice to display the GRAPH/LIST: LIST screen.
4. Select the SPREAD SHEET softkey.
5. Complete the ASCII SAVE function menu.
Example setup shown in Figure 3-8 defines the file name L-IDVG, enables
output of the unit with data, sets the delimiter to comma, sets the string mark to
double quotation mark, and enables output of all data (from index 1 to
maximum).
6. Select the EXECUTE softkey to start saving.
You can read the file using spreadsheet software such as Lotus 1-2-3, as shown in
Figure 3-9.
Figure 3-8 Saving Spreadsheet Data
* DI SK DA TA : C:\D4156
FILE CATALOG
FORMAT: DIR:/PRNOTE
FILE NAME SIZE[byte] DATE TIME [COMMENT]
IDVG DAT 13488 01-02-08 00:12 []
IDVG TIF 47078 01-02-08 00:17 -----------
0/2
FUNCTION :ASCII SAVE
NAME L-IDVG
UNIT ON
OUTPUT DATA (INDEX NO) DELIMITER COMMA
1 <--> MAX STRING MARK " "
Mounting directory
