Agilent 4155C/4156C User’s Guide Vol.1, Edition 11 2-3
Installation
Requirements
Requirements
This section contains information on:
• power requirements
• power cables
• line fuse and line voltage selectors (for the 41501A)
• ventilation requirements
• operating environment
• storaging/shipping environment
Power Requirements
The 4155C/4156C can operate from any single-phase ac power source supplying 90
to 264 V at 47 to 63 Hz. The maximum power consumption is 450 VA for the
4155C/4156C/41501A, and 350 VA for the 41501B. For details, see Chapter 8.
Power Cable
CAUTION Before applying ac line power to the 4155C/4156C or the 41501A/B, ensure that the
correct power cable is used.
In accordance with international safety standards, this instrument is equipped with a
three-prong power cable. When connected to an appropriate ac power outlet, this
cable grounds the instrument frame. The type of power cable shipped with each
instrument depends on the country of destination. Refer to the following table for
the Agilent part numbers of the power cables available.
If the plug on the cable does not fit the power outlet, or the cable is to be attached to
a terminal block, cut the cable at the plug end and re-wire it. This work should be
performed by a qualified electrician, observing all local electrical codes.
The color coding used in the cable will depend on the cable supplied. If a new plug
is to be connected, it must meet local safety requirements and include the following
features:
• adequate load-carrying capacity (see Chapter 8)
• ground connection
• cable clamp
