3-4 Agilent 4155C/4156C User’s Guide Vol.1, Edition 11
Connecting to Network
Executing LAN Interface Test
Executing LAN Interface Test
Before connecting the 4155C/4156C to the network, you should check the operation
of the LAN interface installed in the 4155C/4156C. Do this by executing the LAN
interface test as shown below.
1. Turn the 4155C/4156C on.
2. Attach the LAN I/F test adapter (Agilent part number 04155-61631, furnished
with the 4155C/4156C) to the LAN connector on the rear panel.
3. Press the System key, then select the CALIB/DIAG softkey to display the
SYSTEM: SELF-CALIBRATION/DIAGNOSTICS screen.
4. In the CALIB/DIAG field, select the DIAG softkey.
5. In the CATEGORY field, select the CPU softkey.
6. Move the pointer to 312 (INT.) LAN Interface using the down-arrow key.
7. Select the EXECUTE softkey to execute the LAN interface test.
If the 4155C/4156C fails the test, contact the Agilent Technologies service office.
