5-38 Agilent 4155C/4156C User’s Guide Vol.1, Edition 11
Print/Plot Function
Output Examples
Screen Dump Output
This is an example of the GRAPH/LIST: GRAPHICS screen dump, in HP-GL
format, using an HP LaserJet printer in landscape mode.
Setup
• Screen: GRAPH/LIST: GRAPHICS
• USER COMMENT on the Screen:
ID-VG CHARACTERISTICS
• SYSTEM: PRINT/PLOT SETUP screen:
*FORM FEED ENABLE
*COLOR/B/W B/W
*PAPER
SIZE A4
FEED DIR LONG SIDE
*INIT STRING \0033&l1O\0033%0B
*TRAILER STRING \0033%A\0033&l0O
• SCREEN DUMP dialog:
SCREEN DUMP
*OUTPUT REGION
*DESTINATION
*LANGUAGE
LOWER RIGHT
PRINTER/PLOTTER
UPPER LEFT X 5%
X 100%
Y 0%
Y 100%
HP-GL
