5-32 Agilent 4155C/4156C User’s Guide Vol.1, Edition 11
Print/Plot Function
Saving Measurement Data Graphs
Saving Measurement Data Graphs
This section describes how to save the list of measurement results displayed on the
GRAPH/LIST: GRAPHICS screen as a PCL, HP-GL, or TIFF file.
Before beginning to save the measurement data graph, check the following:
• SYSTEM: FILER screen
This screen sets the DISK entry field to specify the mass storage device used to
save a PCL, HP-GL, or TIFF file. See Setup Screen Reference manual.
• SYSTEM: PRINT/PLOT SETUP screen
This screen specifies the information to save, paper size for printing/plotting,
and so on. Set all the entry fields properly. See Setup Screen Reference manual.
The following entry fields must be set:
Entry Field HP-GL PCL
HR
PCL
HR
TIFF
DESTINATION
FORM FEED √√√
LINE √√√
COLUMN √√
COLOR/B/W √√√√
PAPER √√√
OUTPUT ITEM √√√√
INIT STRING √√√
TRAILER STRING √√√
