Print/Plot Function
Saving Measurement Data Graphs
To save a measurement result graph:
1. Display the GRAPH/LIST: GRAPHICS screen, then press Plot/Print key.
The 4155C/4156C displays the GRAPH PLOT dialog box.
GRAPH PLOT
*OUTPUT REGION
*DESTINATION FILE
UPPER LEFT X 5%
Y 0%
*PRINT/PLOT COMMENT
*LANGUAGE
PCL
*RESOLUTION
75 DPI
LOWER RIGHT X 100% Y 100%
*PRINT SETUP DATA
YES
*FILE NAME
GRAPH PLOT
*OUTPUT REGION
*DESTINATION FILE
UPPER LEFT X 5%
Y 0%
*PRINT/PLOT COMMENT
*GRAPH TRACE ONLY
NO
*LANGUAGE
HR PCL
*RESOLUTION
75 DPI
LOWER RIGHT X 100% Y 100%
*PRINT SETUP DATA
YES
POSITION
BOTTOM
*FILE NAME
GRAPH PLOT
*OUTPUT REGION
*DESTINATION FILE
UPPER LEFT X 5%
Y 0%
*PRINT/PLOT COMMENT
*GRAPH TRACE ONLY
NO
*LANGUAGE
HP-GL
LOWER RIGHT X 100% Y 100%
*PRINT SETUP DATA
YES
POSITION
BOTTOM
*FILE NAME
