Agilent 4155C/4156C User’s Guide Vol.1, Edition 11 2-9
Installation
Inspection
Figure 2-1 CHANNELS: CHANNEL DEFINITION Screen
To Set the Power Line Frequency
When the 4155C/4156C is shipped from the factory, the power line frequency is set
to 60 Hz. To set the power line frequency correctly for your site, do following:
1. Turn on the 4155C/4156C. And wait until the CHANNELS: CHANNEL
DEFINITION screen is appeared.
2. Press the
System front-panel key, then select the MISCELLANEOUS primary
softkey. The SYSTEM: MISCELLANEOUS screen is displayed.
3. Move the pointer to the POWER LINE FREQUENCY field, then select the 50
Hz or 60 Hz secondary softkey corresponding to the line frequency of your site.
B
CHANNELS: CHANNEL DEFINITION 01JAN10 07:05PM
S
CHANNEL
DEF
USER
FCTN
USER
VAR
E5250A
PROP
NEXT
PAGE
SWEEP
SAM-
PLING
QSCV
DEFAULT
MEASURE
SETUP
MEM1 M
B-Tr
VCE-IC
MEM2 M
FET
VDS-ID
MORE
1/2
SWEEP
Select Measurement Mode with softkey or rotary knob.
*MEASUREMENT MODE
SWEEP
*CHANNELS
MEASURE STBY SERIES
UNIT VNAME INAME MODE FCTN RESISTANCE
SMU1:HR V1 I1 COMMON CONST 0 ohm
SMU2:HR V2 I2 I VAR2
SMU3:HR V3 I3 V VAR1
SMU4:HR V4 I4 V CONST
SMU5:HP 0 ohm
VSU1 VSU1 ------- V CONST
VSU2 VSU2 ------- V CONST
VMU1 VMU1 ------- V ----- ---- DISCHARGE
VMU2 VMU2 ------- V ----- ---- ON
PGU1 -------
PGU2 -------
GNDU ------- ----
To Next Page
