Agilent 4155C/4156C User’s Guide Vol.1, Edition 11 5-11

Print/Plot Function

Printing/Plotting Setup Data Lists

This section describes how to print/plot the data list on the setup screens, except for

the GRAPH/LIST and KNOB SWEEP screens.

Before beginning to print/plot, check the following:

• SYSTEM: MISCELLANEOUS screen

This screen specifies the 4155C/4156C control mode, GPIB address, output

equipment, and so on. Set all the entry fields properly. For more information, see

Setup Screen Reference manual.

• SYSTEM: PRINT/PLOT SETUP screen

This screen specifies the printer/plotter, information to print/plot, paper size, and

so on. Set all the entry fields properly. For more information, see Setup Screen

Reference manual.

The following entry fields must be set:

NOTE Multiple Outputs

If you want to print two or more images on one sheet of paper, set the FORM FEED

entry field to DISABLE for all images, except the last image. Set ENABLE for the

last image.

Entry Field HP-GL PCL HR PCL

DESTINATION √√√

FORM FEED √√√

LINE √√√

COLUMN √√

COLOR/B/W √√√

PAPER √√√

OUTPUT ITEM √√√

INIT STRING √√√

TRAILER STRING √√√
