Agilent Technologies 41501B User Manual

5-12 Agilent 4155C/4156C User’s Guide Vol.1, Edition 11
Print/Plot Function
Printing/Plotting Setup Data Lists
To print/plot the setup data list:
1. Display the setup screen you want to print/plot, then press:
• Plot/Print key
The 4155C/4156C displays the PRINT/PLOT SETUP DATA dialog box.
In this dialog box, three softkeys are available:
PRINT/PLOT Executes the printing/plotting.
PR/PL SETUP Displays the PRINT/PLOT SETUP screen. To close the
PRINT/PLOT SETUP screen, select EXIT softkey.
EXIT Closes the PRINT/PLOT SETUP DATA dialog box and
quits the print/plot function.
2. To set the DESTINATION to PRINTER/PLOTTER, select
PRINTER/PLOTTER softkey.
3. To set the LANGUAGE, select PCL, HR PCL, or HP-GL softkey.
If you select PCL or HR PCL, ignore the RESOLUTION setting. The text font
size depends on the printer you use.
PRINT/PLOT SETUP DATA
*OUTPUT REGION
*DESTINATION
*LANGUAGE
PRINTER/PLOTTER
UPPER LEFT X 5%
Y 0%
PCL*PRINT/PLOT COMMENT
*OUTPUT PAGE CURRENT
*RESOLUTION
75 DPI
PRINT/PLOT SETUP DATA
*OUTPUT REGION
*DESTINATION
*LANGUAGE
LOWER RIGHT
PRINTER/PLOTTER
UPPER LEFT X 5%
X 100%
Y 0%
Y 100%
HP-GL*PRINT/PLOT COMMENT
*OUTPUT PAGE CURRENT
