Agilent 4155C/4156C User’s Guide Vol.1, Edition 11 5-13
Print/Plot Function
Printing/Plotting Setup Data Lists
4. To specify the OUTPUT PAGE, select one of the following softkeys:
CURRENT Selects the currently displayed setup screen.
GROUP Selects the screen group that includes the currently
displayed setup data.
ALL Selects all the setup screens.
5. To set the OUTPUT REGION, enter the following entry fields.
UPPER LEFT Specifies the position of the upper-left corner of the printed
or plotted hard copy.
LOWER RIGHT Specifies the position of the lower-right corner of the
printed or plotted hard copy. (If you set the LANGUAGE to
PCL or HR PCL, ignore the LOWER RIGHT entry fields.)
Select one of the following softkeys, or enter a value using the keyboard or the
ENTRY keys on the front panel. These softkeys are available for each OUTPUT
REGION field.
WHOLE Sets the output region as the entire sheet.
UPPER LEFT Sets the output region to the upper-left quarter of the
paper.
UPPER RIGHT Sets the output region to the upper-right quarter of the
paper.
LOWER LEFT Sets the output region to the lower-left quarter of the
paper.
LOWER RIGHT Sets the output region to the lower-right quarter of the
paper.
STORE REGION Stores the OUTPUT REGION settings in the internal
memory.
RECALL REGION Recalls the latest settings stored in the internal memory.
To set the output region to the upper half of the paper, the OUTPUT REGION
should be defined as follows:
*OUTPUT REGION
UPPER LEFT X 0%
Y0%<--origin of printer
LOWER RIGHT X 100% Y 50%
6. Optional: Enter a comment of up to 58 characters into the PRINT/PLOT
COMMENT field. This comment is printed only when this field is enabled on
the SYSTEM: PRINT/PLOT SETUP screen.
7. To start printing/plotting, select PRINT/PLOT softkey.
8. To close the PRINT/PLOT SETUP DATA dialog box, select EXIT softkey.
