2-18 Agilent 4155C/4156C User’s Guide Vol.1, Edition 11
Installation
Installing Accessories
To Install the 16441A R-Box
Before installing the 16441A R-box, turn off the 4155C/4156C and 41501A/B.
1. Connect the To R-Box terminal on the 4155C/4156C to the Control terminal on
the 16441A rear panel using a 3.0 m or 1.5 m control cable.
2. Connect the instrument measurement terminals to the 16441A input terminals as
follows:
3. Connect the 16441A output terminals to the 16442A/B input terminals, or to the
connector plate input terminals, using 40 cm triaxial cables as shown below:
Instrument
terminals
16441A Input Cable
4155C MPSMU Input Force 3 m or 1.5 m Triaxial Cable
4156C HRSMU Input
(Force/Sense)
3 m or 1.5 m Kelvin Triaxial Cable
41501A/B MPSMU Input Force 3 m or 1.5 m Triaxial Cable
41501A/B HPSMU Input
(Force/Sense)
3 m or 1.5 m Kelvin Triaxial Cable
16441A Output 16442A/B Input or Connector Plate Input
Output Force
a
a. For non-Kelvin connection.
SMU1, 2, 3, 4, 5, or 6
Output Force
b
b. For the Kelvin connection, two triaxial cables must be used to con-
nect the 16441A and the 16442A/B, instead of a Kelvin triaxial
cable.
SMU1 SMU3 SMU5
Output Sense
b
SMU2 SMU4 SMU6
To Next Page
