Agilent 4155C/4156C User’s Guide Vol.1, Edition 11 3-13
Connecting to Network
Using Network
9. Select the PRINT PLOT softkey to start saving.
You can import the graphics file to a document such as a technical report by using
word-processing software. Figure 3-7 shows the actual example of importing the tiff
file to the document.
Figure 3-6 SYSTEM: PRINT/PLOT SETUP Screen
Figure 3-7 Importing Graphics Data
B
SYSTEM: PRINT/PLOT SETUP
S
EXIT
GPIB
PARAL-
LEL
P
P R N01
Select one of the secondary softkeys.
*DESTINATION
*FORM FEED DISABLE *LINE 60 *COLUMN 80
*COLOR/ B/W B/W
*PAPER *OUTPUT ITEM
SIZE A4 TITLE ENABLE
FEED DIR SHORT SIDE DATE&TIME ENABLE
LENGTH -------- PAGE NO. ENABLE
WIDTH -------- USER COMMENT ENABLE
UNIT -------- PRINT/PLOT COMMENT ENABLE
GRAPH TRACE ENABLE
GRAPH FRAME & GRID ENABLE
GRAPH AXIS TEXT ENABLE
GRAPH TEXT ENABLE
*INIT STRING
*TRAILER STRING
RN01
P
RN01
