Print/Plot Function

Printing/Plotting Screen Images

To make a hard copy of a screen image:

1. Display the screen that you want to print out, then press:

a. the front-panel green key

b. Plot/Print key

The 4155C/4156C displays the SCREEN DUMP dialog box.

In this dialog box, three softkeys are available:

PRINT/PLOT Executes the screen dump.

PR/PL SETUP Displays the PRINT/PLOT SETUP screen. To close the

PRINT/PLOT SETUP screen, select EXIT softkey.

EXIT Closes the SCREEN DUMP dialog box and quits the

print/plot function.

2. To set the DESTINATION to PRINTER/PLOTTER, select

PRINTER/PLOTTER softkey.

SCREEN DUMP

*OUTPUT REGION

*DESTINATION

*LANGUAGE

LOWER RIGHT

PRINTER/PLOTTER

UPPER LEFT X 5%

X 100%

Y 0%

Y 100%

PCL

*RESOLUTION

75 DPI
