5-18 Agilent 4155C/4156C User’s Guide Vol.1, Edition 11
Print/Plot Function
Printing/Plotting Measurement Data Graphs
To print/plot a measurement result graph:
1. Display the GRAPH/LIST: GRAPHICS screen, then press:
• Plot/Print key
The 4155C/4156C displays the GRAPH PLOT dialog box.
GRAPH PLOT
*OUTPUT REGION
*DESTINATION PRINTER/PLOTTER
UPPER LEFT X 5%
Y 0%
*PRINT/PLOT COMMENT
*LANGUAGE
PCL
*RESOLUTION
75 DPI
LOWER RIGHT X 100% Y 100%
*PRINT SETUP DATA
YES
GRAPH PLOT
*OUTPUT REGION
*DESTINATION PRINTER/PLOTTER
UPPER LEFT X 5%
Y 0%
*PRINT/PLOT COMMENT
*GRAPH TRACE ONLY
NO
*LANGUAGE
HR PCL
*RESOLUTION
75 DPI
LOWER RIGHT X 100% Y 100%
*PRINT SETUP DATA
YES
POSITION
BOTTOM
GRAPH PLOT
*OUTPUT REGION
*DESTINATION PRINTER/PLOTTER
UPPER LEFT X 5%
Y 0%
*PRINT/PLOT COMMENT
*GRAPH TRACE ONLY
NO
*LANGUAGE
HP-GL
LOWER RIGHT X 100% Y 100%
*PRINT SETUP DATA
YES
POSITION
BOTTOM
