Agilent 4155C/4156C User’s Guide Vol.1, Edition 11 5-45
Print/Plot Function
Output Examples
Output Example
NOTE PCL Mode Output
If you select the PCL mode, the font size of the header line, comment and setup data
depends on the printer.
*** Agilent 4156C GRAPH PLOT *** Jan 10 20:00:00 2001 PAGE 1
ID-VG CHARACTERISTICS
SAMPLE DEVICE 1
VS 0. 0000000000 V
(A) VG -1.000 V
100. m
ID
decade
/div
1. 00p
- 1. 00 VG ( V) 500. m / di v 4. 00
*VARIABLE VAR1 VAR2
UNIT SMU2:HR SMU4:HR
NAME VG VSB
LIN/LOG LINEAR LINEAR
START -1.0000 V 0.0000 V
STOP 4.000 V -2.0000 V
STEP 50.0mV -500.0mV
*CONSTANT
UNIT SMU3:HR
NAME VD
SOURCE 2.0000 V --------- --------- ---------
