7-4 Agilent 4155C/4156C User’s Guide Vol.1, Edition 11
Initial Settings
User-Defined Initial Settings
NOTE Which Screen is Displayed after Getting Setup Files?
If the INIT.MES or INIT.DAT file exists on the diskette, the screen that is displayed
after getting the setup files is as follows.
• if file was created by SAVE
When you create INIT.MES or INIT.DAT file by using SAVE function on the
SYSTEM: FILER screen, you can select one of the following screens to be
displayed after getting the files:
• GRAPH/LIST: GRAPH screen
• GRAPH/LIST: LIST screen
• KNOB SWEEP screen
• CHANNELS: CHANNEL DEFINITION screen
• if file was created by RENAME or COPY
When you create INIT.MES or INIT.DAT file by using RENAME or COPY
function on the SYSTEM: FILER screen, you cannot select which screen is
displayed. The CHANNELS: CHANNEL DEFINITION screen is always displayed
after getting the files.
Files for setting internal memories
If the following files exist on diskette, they are loaded automatically from diskette to
internal memory after you turn on the 4155C/4156C:
• measurement setup files (MEM.MES)
• stress setup files (MEM.STR)
• measurement setup/result files (MEM.DAT)
Where MEM means MEM1, MEM2, MEM3, or MEM4, which correspond to the
four internal memory areas. Only the above types of files can be loaded into internal
memory.
If the same internal memory is specified by multiple files (for example,
MEM1.MES, MEM1.DAT, and MEM1.STR), the priority is:
1. DAT
2. MES
3. STR
