8-6 Agilent 4155C/4156C User’s Guide Vol.1, Edition 11
Specifications
Hardware
Table 8-2 Multiplier Factor of the Offset Current at 10 pA/100 pA Range
Table 8-3 HRSMU Voltage Range, Resolution, and Accuracy
Temperature
Humidity
5 to 60 % RH 60 to 80 % RH
5 to 18 °C
× 2 × 2
18 to 28 °C
× 1 × 2
28 to 40 °C × 2 × 5
Voltage
Range
Set
Reso.
Set Accuracy
a
a. Accuracy: ± (% of reading or setting value + offset value).
Meas.
Reso.
Measurement
Accuracy
a
Max. Current
b
b. Vout is the output voltage in volts.
± 2 V 100 μV ± (0.02 % + 400 μV) 2 μV ± (0.01 % + 200 μV) 100 mA
± 20 V 1 mV ± (0.02 % + 3 mV) 20 μV ± (0.01 % + 1 mV) 100 mA
± 40 V 2 mV ± (0.025 % + 6 mV) 40 μV ± (0.015 % + 2 mV) 100 mA (Vout ≤ 20 V)
50 mA
(20 V < Vout ≤ 40 V)
± 100 V 5 mV ± (0.03 % + 15 mV) 100 μV ± (0.02 % + 5 mV) 100 mA (Vout ≤ 20 V)
50 mA
(20 V < Vout ≤ 40 V)
20 mA
(40 V < Vout ≤ 100 V)
