Introducing the 4155C/4156C
Rear View of the 4155C/4156C
• Intlk terminal
Used in conjunction with interlock function of the 4155C/4156C. If the Intlk
terminal is open, maximum SMU output is limited to 40 V. Be sure to connect
this terminal to the 16442A/B test fixture or connector plate before performing
measurement. If you use connector plate, you must install interlock circuit. For
details on how to install the interlock circuit, see “To Make an Interlock Circuit”
in Chapter 2.
WARNING Dangerous voltage of up to the maximum voltage of SMUs may be present at
force, guard, and sense terminals if the interlock terminal is shorted.
• LAN interface
RJ45 connector. Ethernet IEEE 802.3 10BASE-T for a 10M bps CSMA/CD
local area network.
The 4155C/4156C can be a NFS cluster, and can use a remote printer to make
hardcopies.
• Parallel interface
25-pin parallel I/O interface port for connecting peripheral such as a Centronics
parallel printer.
• GPIB interface
Use Agilent 10833A/B/C/D GPIB cable.
• Ext Trig terminals
Two BNC connectors: one for trigger input, and one for trigger output.
• LINE input receptacle
AC power cable is connected to this receptacle.
• Serial number
You need this serial number when using the telephone assistance program
(Agilent Technologies HelpLine).
