2-22 Agilent 4155C/4156C User’s Guide Vol.1, Edition 11
Installation
Installing Accessories
• To attach an 16441A R-box to the 16442A/B test fixture and the 16440A
selector:
• To attach the 16440A selector to a shielding box:
The figure above shows the spacing of the 16440A screw holes. You need to prepare four
screws and nuts to match the screw holes.
16442A/B Test Fixture
16441A R-BOX
16440A Selector
160
3
3
Units: mm
268
280
260
174
48
