Replaceable Parts 6
5000 Series Oscilloscopes Service Guide 121
MP22 54574-00101 1 Deck
MP23 54574-00601 1 Shield, main
MP24 54574-00602 1 Shield, power supply
MP25 54574-00604 1 Ground spring, display (not shown)
MP26 54574-44901 1 Handle
MP27 54684-00604 E-field shield (not shown)
MP28 54572-94303 1 Label, front panel, 2-channel
MP28 54574-94305 1 Label, front panel, 4-channel
MP30 54574-94306 * Front panel overlay - Simplified Chinese, optional
MP30 54574-94307 * Front panel overlay - Traditional Chinese, optional
MP30 54574-94308 * Front panel overlay - Japanese, optional
MP31 54574-09101 2 Spring - tilt leg (not shown)
MP32 54574-41001 2 Tilting leg
MP34 54574-85401 1 Protective insulator (Attached to main shield of
early production models only. Not required if using
new MP23 main shield.)
MP35 54574-94304 1 Label, MSO cover up
W1 54574-61601 1 Cable, power supply
W3 54684-61602 1 Inverter supply cable
W4 54684-61603 1 LVDS display cable
W5 Power cord 1 Part number varies by country. Contact your local
Agilent sales office for replacement. (not shown)
Tab le 13 Replaceable Parts (continued)
Ref
Des
Agilent Part
Number Qty Description
