96 5000 Series Oscilloscopes Service Guide
5 Replacing Assemblies
6 Disconnect the LCD cables from the backlight inverter board.
7 Unplug the supply cable from the inverter board.
Figure 28 Removing the backlight inverter
LCD Cables
Top Latch
Bottom Latch
Cable Groove
Supply Cable
Display Mount
Bottom Alignment
Post
Top Alignment Post
Cable Guides
