22 5000 Series Oscilloscopes Service Guide
2 Testing Performance
List of Test Equipment
Below is a list of test equipment and accessories required to
perform the performance test verification procedures.
Table 1 List of test equipment
Equipment Critical Specifications
Recommended Model/
Part Number Qty
Digital Multimeter 0.1 mV resolution, 0.005% accuracy Agilent 34401A 1
Power Splitter Outputs differ by ≤ 0.15 dB Agilent 11667A 1
Oscilloscope Calibrator 14 mV to 35 Vdc, 0.1 V resolution, 25 MHz - 500 MHz
sine wave, stability 5 ppm after 1/2 hour
Fluke 5820A 1
Signal Generator 100 kHz - 500 MHz at 200 mVrms Agilent N5181A, Agilent
E4400B, or Agilent 8648A
1
Power Meter/Sensor 1 MHz - 1 GHz ±3% accuracy Agilent E4418B/8482A 1
BNC banana cable Agilent 11001-66001 1
BNC cable Agilent 10503A 2
Cable Type N (m) 609.6 mm (24 in.) Agilent 11500B 1
Shorting Cap BNC Agilent 1250-0774 1
Adapter BNC(f) to banana(m) Agilent 1251-2277 1
Adapter BNC Tee (m) (f) (f) Agilent 1250-0781 1
Adapter Type N (m) to BNC (m) Agilent 1250-0082 or
Pomona 3288 with
Pomona 3533
1
Blocking capacitor Agilent 10240-60001 1
Adapter N(m) to BNC(f) Agilent 1250-0780 1
Feedthrough 50
Ω BNC (f) to BNC (m) Agilent 0960-0301 1
Some parts and equipment are available at www.agilent.com or www.parts.agilent.com.
