Agilent Technologies 5000 Series User Manual

66 5000 Series Oscilloscopes Service Guide
4 Troubleshooting
Troubleshooting Flowchart
The following flowchart describes how to troubleshoot 5000
Series oscilloscope models.
Start
Test Power Supply
Okay?
Test System
Board
Okay?
Test Display
Okay?
End
Replace Power
Supply
Replace System
Board
Replace Display
Yes
Yes
Yes
No
No
No
Test AC Input
Board
Okay?
Replace AC Input
Board
Yes
No
