48 5000 Series Oscilloscopes Service Guide
2 Testing Performance
Agilent 5000 Series Oscilloscopes Performance Test Record
Tab le 9 Performance Test Record
Serial No. ______________________________________ Test by _____________________________
Test Interval ____________________________________ Work Order No. ______________________
Recommended Next Testing ________________________ Temperature ____________
Voltage Measurement Accuracy
Range Oscilloscope Calibrator
Setting
Test Limits Channel 1 Channel 2 Channel 3* Channel 4*
5 V/Div 35 V 34.04 V to 35.96 V ________ ________ ________ ________
2 V/Div 14 V 13.616 V to 14.384 V ________ ________ ________ ________
1 V/Div 7 V 6.808 V to 7.192 V ________ ________ ________ ________
500 mV/Div 3.5 V 3.404 V to 3.596 V ________ ________ ________ ________
200 mV/Div 1.4 V 1.3616 V to 1.4384 V ________ ________ ________ ________
100 mV/Div 700 mV 680.8 mV to 719.2 mV ________ ________ ________ ________
50 mV/Div 350 mV 340.4 mV to 359.6 mV ________ ________ ________ ________
20 mV/Div 140 mV 136.16 mV to 143.84 mV ________ ________ ________ ________
10 mV/Div 70 mV 68.08 mV to 71.92 mV ________ ________ ________ ________
5 mV/Div 35 mV 34.04 mV to 35.96 mV ________ ________ ________ ________
2 mV/Div 14 mV 13.232 mV to 14.768 mV
Bandwidth Model Test Limits Channel 1 Channel 2 Channel 3* Channel 4*
505x 3 dB at 500 MHz ________ ________ ________ ________
503x 3 dB at 300 MHz ________ ________ ________ ________
501x 3 dB at 100 MHz ________ ________ ________ ________
Horizontal ∆t Accuracy
Generator Setting Test Limits Results
Period 100 µs 99.8 µs to 100.2 µs ________
Period 100 ns 99.8 ns to 100.2 ns ________
Period 10 ns
1
9.93 ns to 10.07 ns ________
Period 5 ns
2
4.96 ns to 5.04 ns ________
1
100 MHz models
2
300 MHz and 500 MHz models
Time Scale
Accuracy
Limits
TSA Limit: 25 ppm
Time Scale Accuracy is a warranted specification for
5000 Series oscilloscopes manufactured after January
1, 2008.
Measured
error
(ppm)
________
Pass/Fail
________
