Testing Performance 2
5000 Series Oscilloscopes Service Guide 49
Trigger Sensitivity Test Limits Channel 1 Channel 2 Channel 3* Channel 4*
Internal trigger
500 MHz models 0.6 division at 500 MHz ________ ________ ________ _______
300 MHz models 0.6 division at 300 MHz ________ ________ ________ _______
100 MHz models 0.6 division at 100 MHz ________ ________ ________ _______
External trigger, 2-channel models
± 1 V range:
5052A 200 mV at 500 MHz ________ ________ ________ ________
5032A 200 mV at 300 MHz ________ ________ ________ ________
5012A 200 mV at 100 MHz ________ ________ ________ ________
± 8 V range:
5052A 500 mV at 500 MHz ________ ________ ________ ________
5032A 500 mV at 300 MHz ________ ________ ________ ________
5012A 500 mV at 100 MHz ________ ________ ________ ________
External trigger, 4-channel models
5054A, 5034A, 5014A 500 mV at 100 MHz ________ ________ ________ ________
* Where applicable
Tab le 9 Performance Test Record (continued)
