Chapter 1 Introducing the Agilent 5530
Introduction
1-2 Getting Started Guide
1
Introduction
This chapter provides an overview of the Agilent 5530 Dynamic Calibrator
and briefly describes the types of measurements you can make with it.
Figure 1-1 shows the various components used in a typical system
configuration.
Figure 1-1. Agilent 5530 set up for a typical linear measurement
1
Agilent 5519A/B Laser
Head
2 Agilent 10766A Linear
Interferometer with an
Agilent 10767A Linear
Retroreflector attached
3 Height adjuster
4 Personal Computer (PC)
5 Agilent 10888A Remote
Control Unit (optional)
6 Agilent E1738A Air
Sensor (optional)
7 Agilent 10767A Linear
Retroreflector
8 Agilent E1737A Material
Temperature Sensor
(optional)
9 Agilent 10753B Tripod
8
1
2
5
9
6
8
3
7
4
3
