Chapter 4 Using the Agilent 5530 for the First Time
Task 6: Exiting the Metrology Software
4-20 Getting Started Guide
4
a. Select the down arrow on the right side of the Disk Drives box.
b. Select a disk drive.
4 If necessary, in the Directories box, select the directory in which you want
to save the data.
The default is shown in the Current Path field below the Disk Drives box.
You must choose one of the directories shown (you cannot create a new
directory on this screen).
5 Type a name for the data file (up to eight characters) in the File Name
field below the files box.
6 Select OK.
The system saves the file and returns you to the Metrology Main Menu.
Task 6: Exiting the Metrology Software
To exit the software, follow these steps:
1 Return to the Main Menu, then select Quit.
A window is displayed asking if you are sure you want to quit.
2 Select Yes to quit. Select No or press Enter to return to the Metrology
Main Menu.
NOTE
The “X” button that appears in the upper right corner of the Metrology
GUI screens is inoperable. Clicking on this “X” button on most of the
Metrology screens will not exit the Metrology software
Now that you have completed this tutorial, you are ready to learn more
about the software. See Chapter 5.
