Chapter 4 Using the Agilent 5530 for the First Time
Task 2: Setting Up the Software
4-6 Getting Started Guide
4
Task 2: Setting Up the Software
NOTE The following instructions assume that you have the Agilent 10747F
Metrology Software installed on your computer and you know how to use
Microsoft Windows. For complete instructions on setting up the
Agilent 10747F Metrology Software and general software information, see
Chapter 5.
For most of your measurements, you follow a basic path through the
software:
• setting up the laser and hardware
• setting up the measurements
• collecting data
• analyzing the data you collected
To help you navigate through the measurements, the button for the next
screen in the basic path is colored green. (This is not necessarily the same
as the default selection, which is highlighted with a black border.)
1 In Windows, click the Start button, then select Programs.
2 Select Laser Metrology as shown in Figure 4-4.
