Chapter 4 Using the Agilent 5530 for the First Time
Introduction
4-2 Getting Started Guide
4
Introduction
This chapter steps you through a simplified linear measurement you can
perform on a table or desktop. This tutorial will allow you to get
comfortable with the Agilent 5530 before you set it up on a machine to
make an actual calibration. For this tutorial, you need a straightedge and
the measurement template provided on page 4-21, in addition to the
Agilent 5530 components. Figure 4-1 shows the components set up for the
tutorial.
Figure 4-1. Components set up for the tutorial
1
Personal computer with
metrology hardware and
software installed
2 Straightedge
3 Retroreflector assembly
4 Interferometer assembly
5 Tutorial measurement
template
6 Laser head
1
2
3
4
56
