Chapter 3 Installing the Software and Connecting Components
Connecting and Turning on Power
3-18 Getting Started Guide
3
Connecting and Turning on Power
To connect power and turn on the system, see Figure 3-12 and follow these
steps:
1 Connect the laser head power cord to the three-prong outlet on the rear
panel of the laser head (see Figure 3-12).
2 Plug the other end of the power cord into an outlet supplying correct
current.
Manual selection of power source voltage is not required. The laser head's
internal power supply automatically adjusts to operate from any power
source whose voltage and frequency range combination are listed next to
the laser head's rear-panel line power module.
3 Press the Power switch on the laser head to the “I” position.
This turns on the laser head.
4 Connect the PC power cord and turn on the PC.
The PC runs through its normal startup routine.
You are now ready to check the installation. Go to Chapter 4 for
instructions to familiarize yourself with the system before you set it up on
a machine to make an actual calibration.
