Chapter 5 Setting Up the Software for a Measurement
Saving Setup Data and Measurement Data Files
5-14 Getting Started Guide
5
4 Select the file name on the list.
5 Select one of the following buttons:
• Setup and Data (Alt s)—recalls both the measurement setup data
and the measurement data file. The last screen displayed before the
data was saved is displayed again.
Double clicking the file name on the file list is the same as selecting
the name (step 4) and then selecting this button.
• Setup Only (Alt o)—Only the setup data from the file is recalled. The
measurement data is erased and the Set Up Laser screen is displayed.
NOTE
To return to the Metrology Main Menu without recalling a file, click
Previous. The setup is not changed and your unsaved measurement data
is not erased.
Saving Setup Data and Measurement Data
Files
You can save measurement data at any time during your measurement
using the following steps. The setup data is saved automatically when you
save measurement data.
The Save Data button is on both the Metrology Main Menu and the
Analyze Data screen.
To save data, follow these steps:
1 Go to the Metrology Main Menu or the Analyze Data screen.
2 Select Save Data.
The Save Data screen is displayed (Figure 5-6).
To Next Page
