Chapter 1 Introducing the Agilent 5530
Overview of Laser Calibration
1-6 Getting Started Guide
1
measurement systems provide higher accuracy than other types of
calibration systems. The Agilent 5530 offers even more reliability because
it uses Agilent’s two-frequency laser technique, which virtually eliminates
problems resulting from changes in beam intensity.
Figure 1-2. Six degrees of freedom
1 Pitch
2 Yaw
3 Roll
4 Horizontal straightness
5 Vertical straightness
6 Linear displacement
1
23 4 5
6
