Agilent Technologies 5530 Getting Started Guide

Chapter 6 Making the Measurement
Mounting the Laser Head on the Tripod
Getting Started Guide 6-3
6
Figure 6-1. Laser head, mounting plate, and tripod
1
Laser head
2 Handle
3 Elevation adjustment nut
4 Azimuth adjustment knob
5 Slide adjustment knob
6 Mounting plate retention
screw
7 Tripod
8 Knob to lock height
adjustment in place
9 Leg locks
10 Knob to stiffen leg
support
11 Height adjustment knob
12 Knob to lock the
rotation of the mounting
plate
13 Mounting plate
2
1
13
12
3
4
5
6
7
8
9
9
10
11
