184 Operation Manual
10 Configuration
5
Scan the barcode for the entry.
6 Scroll to the next line for the consumable item, then scan
its barcode.
7 After scanning all desired items, scroll to Enter to save, Clear
to abort.
8 Press [Enter] to save the scanned data, or press [Clear] to
abort the process and discard the scanned data.
9 After pressing [Enter], the GC will beep once when the
data system and GC successfully synchronize their data.
If the data system online session is not running, you will not
see the new configuration data. You will need to open the
data system online session, then rescan the information.
To scan configuration data using the G3494A USB barcode reader
Refer to the online help available in the data system.
To uninstall the RS-232 barcode reader
To uninstall the barcode reader, disable it before
disconnecting it.
1 Press [Options], scroll to [Communications], and press
[Enter].
2 Scroll to BCR/RA connector, then press [Mode/Type].
3 Select Disable BCR/RA connection, then press [Enter] to
accept.
4 Turn off the GC.
5 Unplug the barcode reader from the GC and disconnect it
from power.
Table 22 Scannable configuration data
Columns Liners Syringes
Part No. Part Number Part Number
Serial No. Lot Number Lot Number
